H2 Division
We provide the best technique & service
H2 Division
Korea
Hydrogen Sensor Chip & Module, Monitoring System and Inspection Device for Production
Hydrogen Sensor For FCEV
| Metric | Min | Max | Units | |
|---|---|---|---|---|
| ★ Characteristics : | ||||
| 1 | H2 Range (in Air) | 0.25 | 4.0 | % |
| 2 | Voltage input | 12 | 24 | V dc |
| 3 | Output(Sensing Range) | 0.5 | 4.5 | V dc |
| 4 | Power Consumption(RT) | 0.10 | 0.15 | A |
| 5 | Response Time | 1.58 | sec | |
| 6 | Recovery Time | 1.92 | sec | |
| Environment Conditions : | ||||
| 7 | Ambient Temperature | -40 | 100 | °C |
| 8 | Relative Humidity | 5 | 95 | %RH |
Hydrogen Sensor For Infrastructure
| Metric | Min | Max | Units | |
|---|---|---|---|---|
| ★ Characteristics : | ||||
| 1 | H2 Range (in Air) | 0.25 | 10.0 | % |
| 2 | Voltage input | 12 | 24 | V dc |
| 3 | Output(Senting Range) | 0.5 | 4.5 | V dc |
| 4 | Power Consumption(RT) | 0.10 | 0.15 | A |
| 5 | Response Time | 1.58 | sec | |
| 6 | Recovery Time | 1.92 | sec | |
| 7 | Data Storage Copacity | 1,024 | G Byte | |
| 8 | Accuracy | 0.07 | % | |
| Environment Conditions : | ||||
| 9 | Ambient Temperature | -30 | 100 | °C |
| 10 | Retative Humdity | 4 | 90 | %RH |
